1M Shots Life Precision Injection Molds 1 - 20 Cavity Moulds For Plastic Injection

Name: 1M Shots Life Precision Injection Molds 1 20 Cavity Moulds For Plastic Injection
Brand: MID MOULD
Price: 1 USD

Ask Latest Price

Video Channel

Brand Name :MID MOULD

Place of Origin :Dongguan, China

MOQ :1 set

Payment Terms :50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment

Delivery Time :25–45 working days (longer for complex tools)

Certification :ISO9001,FDA,ISO13485

Price :USD $3,000–$50,000 per set (depending on complexity)

Packaging Details :Wooden case + anti-rust oil + protective film + packing list

Supply Ability :20–35 sets per month, depending on structure

Product :Precision Injection Molds

Mould life :250000-300000shots,200~1 M available,300,000shots,000 times

Shaping mode :Plastic Injection Mould,Plastic injection molding,Compression Mould

Cavity :Multi Cavity,as per client's requirement

Design software :CAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE

Mould material :P20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 etc,H13

Application :Home Appliance,Industrial,Automotive,various range,Machine

Mould base :non-Standard plastic injection mould,World standard,European standard,LKM.HASCO,HASCO standard

Surface treatment :sandblasted,Texture,anodizing black,clear painting,Polishing

Size :as samples/drawings,customized accepted,Customized Size

Mold runner :Hot&Cold runner you can choose,Hot runner and code runner

Contact Now

Add to Cart

View Product Description

Product Technology

Through extensive simulation and optimization, combined with imported steel and high-precision machine tools, Precision Plastic Molds excel in precision, lifespan, and production efficiency, making them particularly suitable for products requiring extremely tight tolerances.

Process Flow

Product Evaluation and Mold Design
Mold Flow Analysis and Optimization of the Glue Feeding System
High-Precision CNC and Wire EDM
Assembly and Dynamic Mold Testing
Mold Trial and Parameter Optimization

Product Specifications

Item	Parameter Description
Mold Type	High-Precision Plastic Mold
Mold Material	H13 / 1.2344 / S136
Cavity	1–20
Mold Life	Over 1 Million Molds
Part Accuracy	±0.01–0.015mm
Surface Treatment	Mirror Polishing / Chrome Plating / Nitriding
Applicable Materials	POM / PC / ABS / PPS
Cooling System	Independent High-Efficiency Cooling Circuit
Heat Treatment	Vacuum Quenching / Nitriding
Product Cycle	45–70 Days

Product Applications

High-Precision Components
Strict Appearance Components
Engineering Plastic Functional Components

Product Advantages

Ultra-High Precision: ±0.01mm
Mold Life: Up to One Million Molds
Efficient Cooling: Improves Production Efficiency
Stable Operation: Consistent Quality

FAQ

Q1: Can Accuracy Be Guaranteed? ±0.01mm?

A1: Yes. High-end processing equipment and testing guarantee this.
Q2: Is the mold suitable for engineering plastics?

A2: Yes. It can mold high-strength plastics.
Q3: What is the expected mold lifespan?

A3: Over 1 million molds.
Q4: Is full testing provided?

A4: A full dimensional inspection report is provided.
Q5: What is the production lead time?

A5: Typically 45–70 days.

Customized Services

We provide full-process customization services, from mold design and precision requirements to surface treatment.
